Campus network of a university

Views in this map

1. 1
   CampusFive buildings on one core: the internet edge on top, closets and access points below.
2. 2
   VLANsEvery device by network segment; each building’s distribution pair routes between them.
3. 3
   Science buildingIts distribution pair fans out to five closets, one per floor.
4. 4
   Floor 3 closetOne closet’s switch stack, its six access points and the wired devices on the floor.

Campus ‹ › VLANs ▸ Science building ▸ Floor 3 closet

Flows to play

• ▷
  A dataset goes to the research networkA 2 TB sequencing run leaves by the Science DMZ, around the firewalls.
• ▷
  A student joins Wi-FiFrom the access point in the third-floor lounge to an address and the internet. In the Floor 3 closet view.

The model behind it

69 records of 11 types. Every box on the map is one of them, so the filters and the record panel read the same data.

• Device groups 19
• Switches 17
• VLANs 8
• Buildings 6
• Access points 6
• Wiring closets 5
• Servers 3
• 4 more types 5

Filters

Vendor and Firmware status: pick a value and everything else fades.
